Machine Introduction
The hydraulic semi-automatic horizontal baler is designed for continuous and efficient compression of recyclable materials. The machine adopts a horizontal baling structure and hydraulic compression system, enabling large-volume materials to be compressed into high-density bales.
Materials are fed manually or by conveyor into the compression chamber. After reaching the preset bale length or pressure, the machine automatically compresses the material, while bale tying is completed manually. The finished bale is then pushed out continuously for convenient handling and transportation.
Compared with vertical balers, the semi-automatic horizontal baler offers higher processing capacity, improved efficiency, lower labor intensity, and better suitability for continuous operation.
Typical applications include the following:
- Cardboard, carton boxes, OCC paper, newspapers, and packaging paper
- Plastic films, PET bottles, woven bags, plastic containers, and soft plastics
- Textile waste, cotton, fabric scraps, clothing, and fiber materials
- Aluminum cans, light metal scrap, and industrial recyclable waste
- Agricultural waste, straw, foam, and other loose materials
The machine is widely used in recycling plants, packaging factories, warehouses, printing plants, supermarkets, logistics centers, textile factories, and waste management facilities.
Model Parameters:
| Model | GSB-51111 | GSB-51311 | GSB-51511 |
| Bale Size (L×W×H) (mm) | 1100×1100×(600-1000) | 1300×1100×(600-1000) | 1500×1100×(600-1000) |
| Number of Straps (PCS) | 4 | 5 | 6 |
| Main Cylinder Force (T) | 80×2 | 100×2 | 125×2 |
| Hydraulic Power (kW) | 30 | 37 | 45 |
| Dimension (L×W×H) (mm) | 1640×2430×4140 | 1860×2450×4160 | 2080×2480×4180 |
| Weight (kg) | Approx 7500 | Approx 8500 | Approx 9800 |
The above models are general standard models. Please contact our staff for other required models, and we can also provide specialised customisation services based on your needs.
Technical Highlights
High Processing Capacity
Horizontal continuous feeding design enables efficient handling of large-volume recyclable materials.
High Bale Density
Powerful hydraulic system produces compact and dense bales, reducing storage and transportation costs.
Semi-Automatic Operation
Automatic compression and bale pushing combined with manual tying provide a cost-effective and efficient baling solution.
Stable Hydraulic Performance
High-quality hydraulic components ensure reliable operation, low failure rate, and long service life.
Continuous Feeding Design
Supports conveyor feeding and continuous operation for improved working efficiency.
Wide Material Compatibility
Suitable for paper, cardboard, plastics, textiles, films, PET bottles, and various recyclable materials.
Optional Customization
Different feeding methods, bale sizes, conveyor systems, and power configurations can be customized according to customer requirements.
